Sale! GENERATOR STATOR SUZU DL VSTROM 14-16′ 18-19′
- $279.00
- $83.70
Plug-and-play replacement generator stator from RM Stator.Dimensions:Interior diameter:54mmExterior diameter:119mmThickness:26mmLength of wires stator to grommet:170mmLength of wires grommet to plug: 270mmLength of pickup coil's wire to grommet: 150mmOther
- 100% Happiness Backed or Your Money Back
- Free Delivery on 30+ Orders
- 60-Day Hassle-Free Returns
Plug-and-play replacement generator stator from RM Stator.
Dimensions:
- Interior diameter:54mm
- Exterior diameter:119mm
- Thickness:26mm
- Length of wires stator to grommet:170mm
- Length of wires grommet to plug: 270mm
- Length of pickup coil’s wire to grommet: 150mm
Other specifications:
- Number of wires: 5
- Number of plugs: 2
- Number of pins: 5
- Number of poles: 18
- Wire to wire resistance:
- Alternator: Yellow to Yellow = 0.6 ohms +-20%
- Alternator: Yellow to ground = O.L
- Pickup: Green to Red = 192 ohms +-20%
Details:
- < li>Direct replacement to your original unit
- Plug-and-play, direct fit, easy installation
- Highest grade of lamination materials
- Highest grade of copper winding, resistant to 200 degrees Celsius
- Pick up pulsar coil included
- Connectors included
- Rubber grommet included
- All products shipped are tested
Cost:
$25
Free Shipping:
We offer free shipping on orders over $30. Please check the free - shipping eligibility at checkout.
Delivery Time:
It usually takes [3-5] business days for standard shipping. Please note that this is an estimated time frame and may be affected by local holidays, and unforeseen circumstances.
![Generator Stator Assorted Suzuki Models [Refer to Fitments] (RMS010-101413)](https://www.motopistons.com/wp-content/uploads/2025/6/1749474125/generator-stator-assorted-suzuki-models-refer-to-fitments-rms010-101413-1749474129.webp)
